Product Name : 91 Series Push-To-Reset Circuit Breaker
Product Description

91 Series Push-to-Reset circuit breaker is a unipolar, single-push reset thermal protector product, used to protect motor equipment. Precise in design. Commonly known as Blender circuit breaker/ Disposer Circuit breaker

Products of 91 Series are smaller in volume, and it's used on motor protection, suitable for electrical appliances with small space.

91 Series is 0.5A--10A. Suitable for vacuum cleaner, blender, meat grinder, waste disposer, coffee grinder, Chinese medicine mill, microwave etc.

UL/CUL(North America), CCC(China), TUV(Europe), VDE(Europe), KC(Korea) certified. Passed RoHS environmental protection certification…

Inquiry
Product Introduction

Key Features

  1. Following UL1077 Standard, EN60934 Standard, IEC60934 Standard.
  2. Small current circuit breaker. Small in volume. Precise in action.
  3. (Cadmium free contacts)Comply with European environmental protection requirements.
  4. Trip Free Cycling.

Ratings

  1. Current rating range : 0.5A--10A
  2. Input voltage rating : 125/250VAC; 32/50VDC
  3. Interrupting Capacity : 125/250VAC x 1,000A(UL 1077)

Testing Performed

  1. Current test : 200% current full-inspect test
  2. Dielectric Strength Test : 1500VAC/min
  3. Mechanical life test

Safety Certification

  • Electrical appliances certification : UL, CCC, CB, TUV, VDE, KC
  • Environmental standards : RoHS, REACH

Add-on Service

Provide customer nameplates and nuts for easy fixing on electromechanics.

As for package, we provide customers with customized services.

Assist customers in choosing the specification of protectors and installation methods.
